LM2596 DC-DC Buck Converter Step Down Power Module

Buck Converter (LM2596)

The LM2596 DC-DC Buck Converter Module is a reliable and efficient step-down power supply designed to deliver stable output for a wide range of electronic applications. Capable of supporting up to 3A load current, it offers excellent line and load regulation, ensuring consistent performance even under varying input conditions.

As a switch-mode power supply, the LM2596 provides significantly higher efficiency compared to traditional linear regulators, particularly when working with higher input voltages. This makes it an ideal choice for applications such as embedded systems, battery-powered devices, DIY electronics, and general-purpose voltage regulation tasks where efficiency and thermal performance are important.

Specification :

• Input voltage: 3-40V
• Output voltage: 1.5-35V(Adjustable)
• Output current: Rated current is 2A, maximum 3A
• Switching Frequency: 150KHz
• Operating temperature:Industrial grade (-40 to +85 )
• Conversion efficiency: 92%(highest)
